COLO-Line
COLO
The manual powder coating plant includes powder coating oven and powder spray booth, suitable for continuous batch production of various workparts, such as wheels, frames, profiles, metal shelves, cylinders, etc.
This powder coating plant consists of manual powder coating machine, pass thru type spray booth and gas curing oven with trolley, specially designed for our Malaysia customer for the application of long length workparts who requires batch production with saving budget.
If you need powder coating line products of various sizes, we can customize them according to your needs.
1. Digital controller allows precise setting and reading electric data
2. Three pre-set application programs stand for flat parts, profiles and re-coating
3. 100kv manual spray guns delivers high transfer efficiency with long time working
4. 60lbs fluidizing powder hopper is welled sealed to avoids damp and contaminated.
5. Flexible trolley with wheels can be moved everywhere
6. The anti-static powder hose is smooth for powder conveying.
1. Top track of powder coating booth could be connected to the powder coating line conveyor to achieve continuous production.
2. This booth is designed with dual working station that operators could coat both sides.
3. Powerful fan supply efficienct wind, reduces air consumption with low noise level.
4. PLC control the fan working and precisely set the interval of filter cleaning.
Pass Thru Powder Coating Spray Booth Specifications
| Operating Dimensions | Width620*Depth2920*Heght1500mm |
| Overall dimensions | Width1200*Depth3000*Heght2033mm |
| Weight | 500kg |
| Power Supply | 220V/380V, 3Phase, 50-60HZ |
| Fan Power | 4kw |
| Filter Count | 6 pcs, Quick-release Type |
| Filter Material | Polyester |
| Filter Cleaning | Pneumatic |
1. Using PLC system to control all heating process, accurate and conveninet.
2. Riello burner fully burns fuels (gas or diesel), quickly reach to required temperature.
3. Circulation fans causes uniform temperature in the entire chamber that results in quality cured finishes.
4. 100 mm thickness rockwool board always keeps the chamber with minimum heat loss.
5. We can custom powder coating ovens with required sizes, such as 6m, 7m, 8m, or more.
Trolley Powder Curing Oven Specifications
| Worksize Dimensions | Width1800 * Height1800 * Depth5000 mm |
| Overall Dimensions | Width2100 * Height2200 * Depth5200 mm |
| Power Supply | LPG / Gas / Diesel |
| Voltage/Frequency | 380V/220V (50-60Hz) |
| Warm-up Time | 15-30 min. (180° C) |
| Temperature Stability | < ± 3.0-6°C |
| Temperature | Max. 250° C |
| Transport System | Two trolleys |
| Burner | Italy Riello, 10,0000cal |
| Circulation/ Air flow | Vertical ,Variable through holes on the walls |
| Ventilation Performance | 8288-16576m3/h |
| Motor Power | 7.5kW |
| Warranty | 12 months |
