Powder Coating Paint Gun Lifter for Sale

-For continuous coating
-Easy adjustment stroke & speed
-Increase production & quality
-Minimizes labor cost.
-Digital controller
-80 storable programs
-Carry up to 12 pcs spray guns
  • COLO-2000D

  • COLO

Powder Coating Paint Gun Lifter for Sale

The powder coating gun lifter is used for consistent and uniform painting in automatic line. The spraying guns are mounted on an arm extended from a carriage. Whose movement is programmed in various speeds & stroke to suit conveyor speed & object height respectively.

The smart controllor and keypad enables you to punch in user-friendly parameters which can be viewed on digital display, especially the top limit point and bottom limit point can be easily set and remembered online.

powder coating gun lifter

Powder Coating Gun Lifter Advantages

  • The user-friendly digital controller is memerized for 80 application programs.

  • Japanese imported frequency convertor with reliability and flexibility.

  • Able to carry up to 12 pcs spray gun both for powder coating or wet painting.

  • Exact stroke length adjustment reduces paint / powder wastage.

  • Reduces Maintenance - Only cleaning & lubrication is required periodically.

Powder Coating Gun Lifter Specifications

Model COLO-2000D
Power Supply AC 220V/110V 50-60hz
Motor Power 0.75kw
Speed 0-0.8m/s(0-50m/min)
Acceleration 1m/second
Max. Loading Capacity 25kgs
Controller Digital
Motor Frequency Adjustable
Stroke 1.5m/2m/2.5m

reciprocating powder coating robot

A1 Light NO1
Light NO2
Upward moving
Downward moving
Auto model Light
Actual value
Program mode
Manual/auto swich key
Top stroke setting
Bottom stroke setting
Speed setting
Power switch ON
Power switch OFF

Powder Coating Reciprocator Problem and Solution

Connect the power supply, but the indicator does not light
PCB problem
Indicator problem
Change or repair pcb
Change indictor
Light NO1  flash
Connection of sensors
Sensors damaged
Check connection
Change new sensors
Light NO 2  flash
Sensor wiring short circuit
Sensors damaged
Check connection
Sensors damaged
Control unit is work ,and in on status, but no moving
Voltage problem
Inverter problem
Mechanical parts jammed
(above 3 problem ,inverter will show error  flash
Check mechanical
Change invert
Unable to change setting numbers and NO2 light flash
Limilted by the model 0
Change in model 0 and resetting
Upper and down stoke change too big or out of control
Mechanical  place changed
Re-adjust the senor place
During move  there are strange sounds and sometime the gun move unstable
Too loose of chain
Tight it and change new chain


Reciprocating Powder Coating Robot Maintenance

1. The chains need be checked and adding machine oil on time. Need tight the chain if the chain is too long. Chain should be changed each year, the chain type is 10A. Please note, when you change the chain please make sure the chain mechanical position is not change.

2. Clean the wheel and metal tube on time, if there are too much dust, please clean it use the knife. Make the working condition clean is the best way.

3. Check if the controller is sealed, if the seal is broken and please change the new one. Clean all the accessories in the controller with air, after cleaning please close it on time, or the dust will come into the controller.

4. Clean and check the base on time, clean the motor with air.

5. If the mechanical situation is changed, please re-adjust the stand point, or the moving will out of control. The method is: push the key ↑ or ↓, let the spray gun move to the middle of the working stroke, then adjust the sensor on the bottom of the base, when the data on the "m" indicated 500 and then the setting is finished.
